In this lecture, we're going to create a new project for our sample application.
2
As mentioned in a previous lecture, I'm going to use TIA Portal version 14 service pack 1.
3
You guys can of course use whichever TIA version you have, as long as it's version 14 service pack 1 or a later version.
4
When you first start TIA Portal, this is the first screen that you'll see. TIA portal has two different environments.
5
The Portal View, which is this one we're on right now, and the Project View, which we're going to see in a second.
6
The Portal View provides a simple navigation in the tasks and data of the project. On the left we have the portals for the different tasks. In the middle you'll find actions for the selected portal.
7
And finally on the right, you'll find a selection panel for the selected action.
8
So now we're in the Start portal.
9
The actions available here are: open an existing project, create a new project, migrate a project, etc.
10
We are going to create a new project.
11
Now we have to define a name for our project.
12
Our application is called Refill.
13
And because it's a work in progress version, we'll call it Refill Work.
14
By pressing enter or clicking on Create, our new project will be created.
15
As you can see, our project was opened successfully.
16
We were going to skip these next steps in the Portal View.
17
Instead, we're gonna go to the Project View where the rest of the application creation process takes place.
18
So now we're in the Project View. The Project View provides a structured view of all components of a project.
19
The Project View has the following main components: at the top you have the menu bar. Below the menu bar you've got the toolbar. Below this toolbar the screen is divided in two different sections. On the left side you'll find the project tree, and on the right side, you'll find the work area.
20
Personally, I do all of my TIA work in the Project View.
21
I don't really use the Portal View except for maybe loading a project.
22
I would recommend you to do the same because the Portal View just doesn't have all the functionality that the Project View has.
23
Stick with the Project View.
24
So let's start by adding a PLC to our application.
25
This is done by clicking on "Add new device" in the project tree on the left.
26
There are four different categories: Controllers, HMI, PC systems, and Drives.
27
We are adding a PLC.
28
This is a controller.
29
For this application, we're using a Step 7 1500 type PLC.
30
Let's select the 1511-1 PN PLC.
31
As you can see, there are different versions of this device.
32
We'll just select the latest version.
33
Now that our PLC is added to our application, the only thing left to do is assigning a name to the PLC.
34
This name should be coherent with your application name.
35
Our application is called Refill Work, so let's change the name of the PLC to PLC Refill Work.
36
We'll close this configuration screen for now.
37
We'll come back to it later.
38
Don't forget to save your application once in a while.
39
You do this by pressing "Save project" in the toolbar.
40
Alternatively, you can use the shortcut command Ctrl+S.
41
I would recommend to make it a habit to press Ctrl+S regularly during your coding process.
42
This way you make sure that your work doesn't get lost.
43
We now have successfully created a new project for our application and we've added a PLC. In the next lecture, we're going to set up the PLC and add input and output modules.
44
Thank you, and see you on the next lecture.
