An engine is a machine designed to convert one form of energy into mechanical energy.
2
Heat engines burn fuel to create heat which is then used to do work.
3
It is a complex machine built to convert heat from burning gas into the force that turns the wheels.
4
The chain of reactions that achieve that objective is set in motion by a spark, which ignites a mixture of petrol,
5
vapor, and compressed air inside a momentarily sealed cylinder, and causes it to burn rapidly.
6
The engine has two types, one is the internal combustion engine, and another one is the external combustion engine.
7
The internal combustion engine is those heat engines that burn their fuel inside the engine cylinder.
8
External combustion engines are those heat engine that burns their fuel outside the cylinder.
9
The engine is one of the most essential parts of the automobile industries
10
or we can also say that the engine is the heart of an automobile.
11
So in this video we'll take a look at the function and construction of each engine parts of an internal combustion engine.
12
So be sure to like this video subscribe to the channel
13
and press the bell icon to get notifications of our new videos.
14
The main parts of an car engine are cylinder block,
15
cylinder head, oil pan, Manifolds Gasket
16
And Piston A piston ring Piston
17
pin Connecting rod Crankshaft Camshaft Flywheels Rod bearing Main bearings And bearing caps
18
Now let's take a look at each of engine parts with details starting with cylinder block.
19
It is the basic framework for the engine and one of the main part of an engine.
20
A cylinder block consists of three parts.
21
The cylinder in which the piston slid up and down, the port or opening for the valves, the passages for the flow of cooling water.
22
The cylinder block is usually made of gray cast iron
23
or aluminium and its alloys while the crank case is fixed to its bottom.
24
Apart from these other parts like timing gear, water pump, ignition distributor, flywheel,
25
fuel pump are also attached to it.
26
Coolant passages are provided in the cylinder walls for the circulation of cooling waters.
27
Cylinder block also carries lubrication oil to various components through drilled passages that is called oil galleries.
28
Cylinder head.
29
The cylinder head is another main part of an engine.
30
It is a joint between the cylinder head and cylinder block.
31
It is usually made up of cast iron and aluminium alloy.
32
The cylinder head is attached to the cylinder block using studs fixed to the block gaskets, which are used to provide a tight leak proof joint between the head and block.
33
The cylinder head contains a combustion chamber above each cylinder, and it also contains valve guides,
34
valve seats, ports, coolant jackets, and threaded holes, four spark plugs.
35
It incorporates passages for the flow of cooling water.
36
There are three different types of cylinder head is available that depends upon the valve and port layout.
37
Loop flow type, offset cross flow type and inline cross flow type.
38
In the loop flow type, the inlet and the exhaust manifolds are on the same side, which facilitates preheating of the intake air.
39
In the offset cross flow type, the inlet and the exhaust manifolds are placed on different sides of the cylinder head.
40
In the inline cross flow type, the valve is positioned transversely and usually inclined to each other,
41
while the inlet and the exhaust manifolds are on different sides of the cylinder head.
42
This arrangement gives better performance, but it is costlier.
43
Crank case.
44
The oil pan and the lower part of the cylinder block together are called the crankcase.
45
It is the bottom portion of the cylinder block, in which the crankshaft is fitted.
46
This is a rigid construction made of grey cast iron or aluminium.
47
Either it can be cast integrally with the block, or can be cast separately, and attached to the block with bolts.
48
The crankcase is shaped simply like a box, having no bottom surface.
49
The function of the crankcase is to provide support for the main journals and bearing of the crankshaft,
50
rigidly maintaining the alignment of their axes of rotation under various engine loads.
51
Oil Pan The bottom half of the crankcase is called the oil pan or sump.
52
It is attached to the crankcase through set screws and with a gasket to make the joint leak proof.
53
The oil pan serves as a reservoir for the storage, cooling, and ventilation of engine lubricating oil.
54
At the bottom of the oil sump, a drain plug is provided to drain out the dirty oil, at the time of oil replacement.
55
Generally, the sump is made of pressed steel sheet, or aluminium alloy casting is also used.
56
The oil pump in the lubricating system draws oil from the oil pan, and sends it to all working parts in the engine.
57
The oil drains off and runs down into the pan.
58
Thus, there is a constant circulation of oil between the pan and the working parts of the engine.
59
Manifolds There are separate sets of pipes attached to the cylinder head, which carries the air -fuel mixture and the exhaust gases, these are called manifolds.
60
It is generally made of cast iron, so that it can withstand the high temperature of the exhaust gases.
61
Gaskets Gaskets are used to provide a tight fitting joint between two surfaces.
62
Gaskets are found in the joint between the cylinder head and the cylinder block, between the crankcase and oil pan,
63
and in between the cylinder block and manifold.
64
materials used for gaskets are cork asbestos rubber gaskets produced by
65
the fuel pro USA are cylinder head gaskets oil pan gaskets manifold gaskets
66
and pump gaskets cylinder liners the cylindrical shape liners are used to avoid the cylinder wear.
67
It is one of the most important functional part to make up the interior of an engine.
68
Cylinder liners can be replaced after they are worn out.
69
These are made of special alloy iron containing silicon, manganese, nickel and chromium.
70
Usually these are cast centrifugally.
71
These liners resistance to wear and corrosion and are the oil hardening type that offers considerably longer life for the engine.
72
There are two types of cylinder liners will be available, they are dry liners and wet liners.
73
Dry liner is made in the shape of a barrel with a flange at the top which keeps it into position.
74
The entire outer surface bears against the cylinder block casting and hence these are machined accurately at both outer and interfaces.
75
Wet liners will be in direct contact with the cooling water at their outer face.
76
Because of this, these liners need not be machined very accurately at the outer surface.
77
However, they have been machined accurately at the inner surface.
78
Pistons.
79
These are the most important engine parts compared to others.
80
The piston is a cylindrical plug that moves up and down in the cylinder.
81
It helps to convert pressure energy obtained by the combustion of fuel into useful mechanical power
82
and it transfer this power to the crankshaft through the connecting rod.
83
The highest position of the piston reaches in the cylinder is called the top dead center
84
and the lowest position it reaches is called the bottom dead center.
85
It is provided with about three to five piston rings that provides a good seal between the cylinder wall and piston.
86
The efficiency and economy of the engine is primarily depend on the working of the piston.
87
The material used for the piston is mainly cast iron and aluminium alloy.
88
It may be either cast or forged.
89
The piston is usually small in diameter than the bore of the cylinder.
90
The space between the cylinder and the cylinder wall is called the piston clearance.
91
This piston clearance provides a space for a layer of lubricant between the piston
92
and cylinder wall to reduce friction generally pissed Piston clearance is 0 .025 mm to 0 .100 mm.
93
Piston Rings
94
The piston rings are fitted into the grooves of the piston to maintain a good seal between the piston
95
and the cylinder wall.
96
The function of piston rings is to form a seal for
97
the high -pressure gases from the combustion chamber entering into the crankcase.
98
The material generally used for piston rings is fine -grained alloy cast iron containing silicon and manganese.
99
It has good heat and wear -resisting qualities.
100
Mainly there are two types of piston rings available.
101
They are compression rings and oil control rings.
102
The number of piston rings used is about two to four compression rings and one to two oil control ring was used.
103
Connecting Rod It is fitted in between the piston and crankshaft.
104
The main function of the connecting rod is to convert the
105
reciprocating motion of the piston into the rotary motion of the crankshaft.
106
Connecting rod in an IC engine is must be light and strong enough to withstand stress and twisting forces.
107
It usually has I -beam cross section and is made of alloy steel of duralumin by drop forging.
108
The small end of the connecting rod has either a solid eye used to connect the piston by the piston pin.
109
The big end of the connecting rod is always split and it is used to connect the crank pin of the crankshaft.
110
Piston Pin The piston pin is also called wrist pin or gudgeon pin.
111
It is used for connecting the small end of the connecting rod and the piston.
112
It is made hollow to reduce weight and it is made from case hardened steel.
113
Mainly there are three types of piston pins available.
114
They are set screw types piston pin.
115
This pin is fastened to the piston by a set screw.
116
Semi -floating piston pin.
117
It is fastened to the connecting rod with the clamp screw.
118
Fully floating piston pin.
119
The pin floats in both the piston bosses and the small end of connecting rod.
120
It is prevented from coming in contact with the cylinder wall by two circlips.
121
Crankshaft.
122
The crankshaft is the engine component from which the power is taken.
123
It is one of the main power transmission sources in all engine parts.
124
It is the first part of the power transmission system, in which the reciprocating motion of the piston is converted into the rotating motion with the help of connecting rod.
125
The crankshaft is made of casting or forging of heat -treated alloy steel and is machined.
126
A crankshaft consists of crankpins, weds, balancing weight and main journals, and oil holes.
127
The front end of the crankshaft carries three devices.
128
They are a gear that drives the camshaft, the vibration damper to control torsional vibration, and the fan belt pulley.
129
This pulley drives the engine fan, water pump, and generator with a V -belt.
130
The rear end of the crankshaft carries flywheel.
131
The flywheel tends to keep the crankshaft running at constant.
132
Camshaft A camshaft is a shaft on which cams are mounted.
133
A cam is a device that changes the rotary motion of the camshaft into the linear motion of the follower.
134
It is responsible for the opening of the valves.
135
A camshaft has several cams along the length.
136
The camshaft is driven by the crankshaft.
137
And it has twice the gears as many teeth as the gear on the crankshaft
138
and it turns at half the speed of the crankshaft.
139
Camshaft made from forged alloy steel.
140
There are three types of the camshaft drive mechanism.
141
They are gear drive, chain drive and belt drive.
142
Flywheel The flywheel used in a transmission system of a vehicle.
143
A flywheel is a heavy steel wheel attached to the rear end of the crankshaft.
144
The size of the flywheel depends upon the number of cylinders and the construction of the engine.
145
The inertia of the flywheel tends to keep the running of the crankshaft at a constant speed.
146
Engine valves These are essential to control the timing of air fuel mixture, entry into the cylinder, and combustion products out of the cylinders.
147
Engine valves are located at the inlet and outlet opening of the engine cylinder.
148
The valves fit on the valve seats in their closed position.
149
Then please share it with your friends.
150
Subscribe to our channel and press the bell icon to get notification of our new videos.
FOR YOU
推薦影片
B21
107 句
Engineer's tool list
Daily ConversationUniversity StudentsWorking Adults
C11
59 句
How does a Thermal power plant work?
Daily ConversationUniversity Students
B11
16 句
What is a kernel? (Briefly explained)
Daily ConversationUniversity Students
B11
135 句
Human Organ Systems Anatomy | 10 Systems in Human Body 3D Animation Video
Daily ConversationUniversity Students
C194 句
who is the Chief Engineer on a ship? what are his responsibilities? -latest-www.maritimeplatform.com
Daily ConversationUniversity Students
B21
132 句
How A Car Engine Works
Daily ConversationWorking Adults
B21
162 句
Introduction to PLC | Siemens PLC Training Course
Daily ConversationUniversity Students
B21
132 句
Video
Daily ConversationUniversity StudentsWorking Adults
B21
183 句
Concept of Electric Current with Train example | TheElectricalGuy
Daily ConversationUniversity Students
B237 句
Embedded Systems Explained in 3 minutes
Daily ConversationUniversity Students
C11
32 句
Structure and Function of a Prokaryotic Cell (Bacteria)
Daily ConversationUniversity Students
C11
96 句
Top 10 Welding Defects in Process Piping (Causes, NDT Inspection & Fixes)
Daily ConversationUniversity Students
本課的詞彙與口語要點
這節 C1 級別的口語課以影片“Car Engine Parts & Their Functions Explained in Details”為素材。 影片中反覆出現的詞有：cylinder, piston, engine, oil, crankshaft。 這段影片共有 150 個句子、2058 個單詞可供跟讀。 講話部分時長為 15:23。 說話人語速平穩，每分鐘約 134 個詞，很適合跟讀。 只有 72% 的單詞屬於英語最常用的 3,000 詞，詞彙難度較高。
影片中的重點詞彙
影片中最難的 15 個單詞，附發音和釋義：
| 單詞 | 發音 | 釋義 |
|---|---|---|
| cylinder 名詞 | /ˈsɪləndɚ/ | 圓柱體 /圓柱體, 圓柱 /圓柱 |
| piston 名詞 | /ˈpɪstən/ | 活塞, 韝鞴 |
| crankshaft 名詞 | 曲軸 /曲軸 | |
| gasket 名詞 | /ˈɡæs.kɪt/ | 墊片 /墊片, 膠圈 /膠圈 |
| liner 名詞 | /ˈlaɪnɚ/ | 郵船 /郵船 |
| camshaft 名詞 | /ˈkæmʃæft/ | 凸輪軸 /凸輪軸 |
| combustion 名詞 | /kəmˈbʌs.t͡ʃən/ | 燃燒 /燃燒 |
| alloy 名詞 | /ˈæ.lɔɪ/ | 合金 |
| flywheel 名詞 | 飛輪 /飛輪 | |
| manifold 形容詞 | /ˈmænɪˌfoʊld/ | 雜多的 /雜多的 |
| aluminium 名詞 | /ˌæl.(j)uˈmɪn.i.əm/ | 鋁 /鋁, 鋼種 /鋼種 |
| exhaust 動詞 | /ɪɡˈzɔst/ | 抽完 |
| forge 名詞 | /fɔɹd͡ʒ/ | 鐵匠鋪 /鐵匠鋪 |
| crank 名詞 | /ˈkɹæŋk/ | 曲柄 |
| float 動詞 | /fləʊt/ | 浮, 漂浮 |
影片中出現的短語動詞
| 單詞 | 發音 | 釋義 |
|---|---|---|
| make up 動詞 | /ˌmeɪk ˈʌp/ | 組成 /組成 |
影片中的語法
說話人最常用的結構，並附上影片中的原話：
| 結構 | 影片中的用法 |
|---|---|
| 被動語態 be + 過去分詞 — 強調發生了什麼，而不是誰做的 | is set · is usually made · is fixed |
| 定語從句 who / which + 從句 — 補充說明人或事物 | heat which is · gaskets, which are |
需要注意的發音
- “sh” 和 “zh” 音: camshaft /ˈkæmʃæft/, vibration /vaɪˈbɹeɪʃən/, compression /kəmˈpɹɛʃ.ən/, notification /ˌnoʊtɪfɪˈkeɪʃn̩/, circulation /ˌsɝkjʊˈleɪʃən/
- 長單詞——注意重音位置: aluminium /ˌæl.(j)uˈmɪn.i.əm/, accurately /ˈæk.jə.ɹɪt.li/, cylindrical /sɪˈlɪndɹɪkəl/, reciprocate /ɹɪˈsɪpɹəˌkeɪt/, notification /ˌnoʊtɪfɪˈkeɪʃn̩/
中文母語者容易讀錯的音：
- /v/ — 不要讀成 /w/，上齒輕觸下唇: vibration /vaɪˈbɹeɪʃən/, vapor /ˈveɪpɚ/, ventilation /ˌvɛntɪˈleɪʃ(ə)n/, groove /ɡɹuv/, reservoir /ˈɹɛz.ə(ɹ).vwɑɹ/
- 詞尾子音 — 要讀清楚，後面不要加母音: gasket /ˈɡæs.kɪt/, camshaft /ˈkæmʃæft/, manifold /ˈmænɪˌfoʊld/, exhaust /ɪɡˈzɔst/, inlet /ˈɪnlət/
- /r/ 和 /l/ 的區別: accurately /ˈæk.jə.ɹɪt.li/, cylindrical /sɪˈlɪndɹɪkəl/, lubricate /ˈluːbrɪkeɪt/, lubricant /ˈlubɹəkənt/, lubrication /ˌluː.bɹɪˈkeɪ.ʃən/
如何用這段影片練習
- 先完整聽一遍影片，不要開口，記下不認識的單詞。
- 用正常速度逐句跟讀，每句重複到你的節奏與說話人一致為止。
- 錄下自己的聲音並與原聲對比，特別注意 cylinder, piston, crankshaft 這類單詞。
什麼是跟讀法？
跟讀法 (Shadowing) 是一種有科學依據的語言學習技巧，最初開發用於專業口譯員的培訓，並由多語言者Alexander Arguelles博士普及。這個方法簡單而強大：您在聽英語母語原聲的同時立即大聲重複——就像是一個延遲1-2秒緊跟說話者的影子。與被動聽力或語法練習不同，跟讀法強迫您的大腦和口腔肌肉同時處理並模模擬實的講話模式。研究表明它能顯著提高發音準確性，語調，節奏，連讀，聽力理解和口語流利度——使其成為雅思口語備考和真實英語交流最有效的方法之一。
